UL 1376 Verified (Gold)

NLC Plug and Play Long-Range Sensor with Lens (Wet-Location)

The NLCEFS106-WHBL is a low voltage Bluetooth wireless PIR/Daylight sensor. The integrated 3.5mm jack is designed for easy installation with socket sensor enabled outdoor luminaires. It provides 360° coverage at heights ranging from 20-40Ft with the standard WHBL102B lens. Setup and commissioning requires the NICOR NLC mobile app (iOS and Android). Additional Lens options are available, see the accessories section.

NLC Real-Time-Clock USB Dongle

The NLCCR01RTC is a real-time clock (RTC) powered via a USB-A receptacle. A CR2032 battery provides backup power, maintaining the internal clock during power outages. The NLCCR01RTC synchronizes all devices within a zone, ensuring precise and consistent scheduling across the entire system. Commissioned via NICOR NLC app (iOS and Android compatible).

NLC Wireless 3-Button Wall Control Switch

The NICOR NLCWP1013SA0 is a line-voltage Bluetooth wireless wall switch. Featuring 3-key control (ON/OFF, DIM+, DIM-), it provides wireless lighting control of NICOR NLC devices via Bluetooth connectivity. The switch can be used to retrofit a standard wall switch and requires a neutral wire connection. Setup and commissioning requires the NICOR NLC mobile app (IOS and Android).

NLC Line-Voltage 7-Button Wall Control Switch

The NLCWP1017SA0 is a 7-button line-voltage Bluetooth switch designed for applications where battery use is not practical. It provides 4 separate scenes, Dim up / Dim down, and ON/OFF functions. It is sized to pair with a Decora wall plate. Setup and commissioning requires the NICOR NLC mobile app (IOS and Android).

NLC Plug and Play Long-Range Controller Node

The NLCWPPA102AUXWC1 is a Bluetooth control node designed for outdoor and wet-location applications. It has an enhanced antenna that supports wireless communication up to 328 feet (100 meters) between system nodes. The UV resistant and IP66 rated enclosure protects against harsh environments while ensuring reliable performance. The device is commissioned using the NICOR NLC app for iOS and Android (iOS and Android).

NLC Wireless 20A Zone and Plug Load Controller with 12V/ECO Port

The NLCPPA104SB1 Series Bluetooth zone controllers feature a 20A relay for controlling higher capacity loads than standard fixture controllers. The NLCPPA104SB1 incorporates external 0-10VDC plus 12VDC output push-in terminals and a RJ45 port to support Eco-Sensors. The NLCPPA104SB1 supports switching of up to 20A plug loads and 1HP motor loads.

NLC Low-Voltage Ceiling Sensor with ECO Sensor and Daylight Harvesting

The NLCEFS107EA0 is a low-voltage, dual-tech ceiling mount room sensor that combines PIR and ultrasonic technologies to provide high accuracy and wide coverage. It is equipped with the AlgoH™ algorithm to maximize detection while reducing false-ON triggers. The NLCEFS107EA0 sensor incorporates daylight harvesting and is intended to operate with a luminaire controller NLCPPA104SB1. The NLCPPA104SB1 is commissioned with the Nicor NLC app.

NLC Line-Voltage PIR/Daylight Occupancy Sensor

The NLCCS107DB1 is a line-voltage, Bluetooth dual-tech occupancy sensor that combines PIR and ultrasonic technologies to provide high accuracy and wide coverage. It also features integrated daylight harvesting. Commissioning via the NICOR NLC app allows the sensor to turn a load on and hold it on if either or both technologies detect movement. Setup and commissioning requires the NICOR NLC mobile app (IOS and Android compatible).

NLC Battery Powered Wireless (BLE) Ceiling Mount Sensor

The NICOR NLCBCS107C1 is a wireless Bluetooth ceiling mount sensor that is battery powered and used with the NICOR NLC system. It has both occupancy sensing and Daylight Harvesting. The NLCBCS107C1 is commissioned with the NICOR NLC app.

NLC Wireless End-Mount PIR/Daylight Sensor

The NLCSPEW1WH-LHW is our line-voltage Bluetooth wireless PIR/Daylight sensor designed exclusively for the NICOR NLC System making it perfect for your Luminaire Level Lighting Controls (LLLCs) needs. Constructed from the highest-rated fire retardant material, this sensor ensures easy installation and operation, which is particularly ideal for retrofit applications. For optimal performance, ensure your retrofit fixtures are 0-10V compatible. Offering 360° coverage at heights from 20ft to 40ft with the standard -LHW lens (high bay, wide pattern). With long-term flexibility, better occupant experience, and cost efficiency compared to non-controlled fixtures, making it ideal for warehouses, garages, gymnasiums, and other industrial spaces. Setup and commissioning requires the NICOR NLC mobile app (iOS and Android).

NLC Wireless Wall Control Switch

The NLC Bluetooth Wireless Wall Switch Series offers two unique switch designs in 3-button and 5-button configurations. Both provide wireless remote control of NLC enabled luminaires as a handheld device or wall-mounted switch. Setup and commissioning requires the NICOR NLC mobile app (iOS and Android). For wall mounting, add the NLCWP1WH wall switch base with faceplate.

NLC Wireless 3.5mm PIR/Daylight Sensor

The NLCSPEJ is a low-voltage Bluetooth wireless PIR/Daylight sensor with a 3.5mm Jack/AUX connector, designed for the NICOR NLC System, perfect for Luminaire Level Lighting Controls (LLLCs). Constructed from high-rated fire retardant material, this sensor offers easy installation and use, with a plug-n-play system for fixtures with a 12V output 3.5mm jack sensor socket ready. Providing 360° coverage at heights from 20Ft to 40Ft, it offers long-term flexibility, better occupant experience, and cost efficiency compared to non-controlled fixtures, making it ideal for warehouses, garages, gymnasiums, and other industrial spaces.
