OWF5 Full Cut-Off LED Wall Pack for Perimeter & Entry Lighting

Wall pack lighting has to cover a lot of ground: secure entrances, light building perimeters, and hold up to the elements, all while staying simple to specify and install. The OWF5 Full Cut-Off LED Wall Pack is built around that reality, pairing a slim, low-profile design with the flexibility of NICOR’s Triple Select platform.

• Triple Select Technology: Adjustable Wattage, CCT (3000K/4000K/5000K), and Distribution
• Delivers up to 178 lumens per watt in a sleek, slim, and low-glare profile.
• Integral photocell standard
• DLC 6.0 Premium Listed
• 5-year limited system warranty

Select the Perfect Light for Every Application

Independent wattage, CCT, and distribution settings let one OWF5 match each application’s lumen output, color, and beam spread. Within each model size, one fixture can serve loading docks, storefronts, and wide-open lots without separate fixtures, reducing inventory needs:

• Wattage: 20/30/40W on the 040S, 60/80/100W on the 100S, or 90/120/150W on the 150S, matched to the size of the space.
• CCT: 3000K, 4000K, or 5000K, to match surrounding site lighting or a municipality’s specification.
• Distribution: Type II, Type III, or Type IV, to shape the throw pattern for a side yard, perimeter, or wide-open lot.

High Output in a Slim, Low-Glare Profile

The OWF5 delivers up to 178 lumens per watt without adding bulk. Its slim, low-profile housing keeps visual obstruction to a minimum on a wall or facade, while the Type II, III, or IV precision lens controls glare and directs light where it’s needed.

Field-Adjustable Wattage, CCT, and Distribution

Internal switches let installers set wattage, color temperature, and distribution in the field—no optic swaps or separate fixtures. Within each model size (040S, 100S, 150S), one fixture covers every wattage, CCT, and distribution combination, reducing the SKUs distributors need to stock.

Flexible Mounting, With Optional Emergency Back-Up

The OWF5 mounts to a surface with its supplied mounting plate, wiring routed through the backplate or knockouts. For code-mandated egress lighting, it also offers an optional internal emergency back-up (4W on the 040S, 8W on all models, or 16W on the 150S, rated for 0°C to 45°C), so one fixture covers both normal and emergency operation without an external battery pack.

Built for Perimeter, Entrance, and General-Purpose Lighting

Built for perimeters, entrances, walkways, and commercial spaces, the OWF5 combines die-cast aluminum, acrylic optics, stainless steel hardware, and a UV-stabilized bronze finish for outdoor durability.

Backed by a 5-Year Warranty

Every OWF5 carries NICOR’s 5-year limited system warranty and is cULus listed for wet locations, IP65 rated, RoHS compliant, and DLC 6.0 Premium Listed, with TM-21 reported L70(9k) life over 54,000 hours.

The OWF5 is available now through NICOR’s agent and distributor network. For a closer look at how it compares to the rest of the wall pack line, visit the OWF4 LED Wall Pack product page, or browse NICOR’s full selection of outdoor wall packs and outdoor security & perimeter lights.

---
