A doorbell should be the last thing a builder hears about after closing. Traditional mechanical chimes made it one of the first. NICOR developed the PrimeChime to fix that, replacing the parts that wear out with a digital chime and an integrated transformer in one unit. Today the PrimeChime family covers full-size, compact, ADA-compliant, and wireless installs, and works with most popular video doorbells.
- Works with most popular video doorbells, with no power or diode kit needed
- Five selectable chime tones and five volume levels with voice-guided setup
- Line voltage, low voltage, and transformer combined in a single unit
- Two-gang, single-gang, ADA strobe, and wireless button options
- UL certified, with a paintable, screwless faceplate
Built to End the Doorbell Callback
Failing mechanical doorbells were the number one callback issue for builders. A traditional chime depends on a separate transformer and a mechanical striker, and each is one more part that can wear, stick, or burn out. NICOR set out to design a doorbell that simply keeps working, and the PrimeChime was the result. It combines line voltage, low voltage, and the transformer in one unit with a digital control board and speaker, so there are fewer components to fail and fewer reasons for a return trip.
Meet the PrimeChime Family
PRCP2
PrimeChime Plus 2 (PRCP2) is the full-size original. It installs in a standard two-gang dual-voltage box, includes two lighted doorbell buttons, and supports separate front and rear door tones. Two units can be daisy-chained (200 ft max total wire length) for larger homes.
PRCP2A
PrimeChime Plus 2A (PRCP2A) adds ADA compliance to the PRCP2 with an integrated blue strobe that flashes when the chime rings. The strobe can be turned on or off, and the optional PRCP2STROBE remote strobe extends visual alerts to another room.
PRMC
PrimeChime Plus 2 Mini (PRMC) brings the same features to a compact unit that fits most non-metallic single-gang junction boxes. It can drive up to two video doorbells at once and daisy-chain up to 10 units (400 ft max total wire length).
PRMC-WL
PrimeChime Plus 2 Mini with Wireless Button (PRMC-WL) pairs the PRMC with a battery-powered wireless button that reaches up to 120 ft in open air. It is ideal for side entrances, back doors, and garages where running new bell wire isn’t practical.
Works with Today’s Video Doorbells
Every PrimeChime is designed to supply the proper voltage for compatible video doorbells, so no power or diode kit is needed. The compatibility list covers Ring, Google Nest, Arlo, Eufy, Wyze, Chamberlain myQ, Lorex, SimpliSafe, Skybell, and more. Two newer doorbells need an adapter, both available as accessories or as kits ordered with the chime:
PRCHIMEADAPT1WH
PRCHIMEADAPT1WH Ring adapter: Required for the Ring Video Doorbell Plus Wired (2nd Gen) and Ring Video Doorbell Pro (3rd Gen). Works with the PRCP2, PRCP2A, and PRMC, and replaces Ring’s own adapter. Order as a kit with the RG suffix.
PRCP2EBADAPT1WH
PRCP2EBADAPT1WH ecobee adapter: Required for the ecobee Smart Doorbell Camera. Works with the PRCP2 and PRCP2A alongside the ecobee chime adapter. Order as a kit with the EB suffix.
Simple Setup, Seamless Look
Every PrimeChime uses a single-button, voice-guided interface to choose from five chime tones (Ding Dong, Westminster, 3-note, 5-note, and 7-note) and five volume levels. Front and rear doors can each get their own tone, so homeowners always know which door to answer. The screwless faceplate is field paintable to blend into any wall, and lighted deco and stucco buttons are available in finishes including white, nickel, copper, black, antique brass, architectural bronze, and polished brass. Each unit is UL certified and backed by a 1-year limited system warranty.
20 Years of a Better Doorbell
The PrimeChime is approaching its 20th anniversary, and the goal behind it hasn’t changed: a doorbell that works the first time and keeps working. Watch for the full story of why NICOR built it in the coming weeks.
The PrimeChime family is available now through NICOR’s agent and distributor network. To find a distributor near you, call 800.821.6283 or email [email protected]. Browse the full lineup of PrimeChime doorbells, or download the NICOR Chimes Compatibility List to check a specific video doorbell.
