LED EMERGENCY LIGHT

This LED thermoplastic emergency lighting unit combines a low-profile, contemporary design in an affordable package. The EML1 Series is available in white and offers universal mounting with testing button and a damp location listing. With fully adjustable heads, the EML1 Series complements any design application.

Category: Tags:

Specifications

  • Injection Molded Thermoplastic ABS Housing
  • UL-947-0 Flame Rating - Flame Retardant
  • Input power 1.15W at 120/277VAC
  • Remote output power 2.4W at 3.6VDC
  • Supports up to two (2) single or one (1) double NICOR remote lamps
  • 90 minute capacity (including remote lamps)
  • Damp Location Rated (0°C - 40°C)
  • Universal Mounting Plate with EZ Quick Connect



Part Number:

EML1-10-UNV-WH - White
EML1-10-UNV-WH-R - White with Remote

Downloads

– EM Catalog
– Sell Sheet
– Spec Sheet
– Installation Instructions
