LED MICRO EMERGENCY LIGHT

The EML5 LED micro emergency light lighting unit offers a you a mini sized unit for those tight spaces or a more discreet application. The EML5 Series is available in white and offers universal mounting, a test button with AC indicator, damp location listing, and a remote capable option. With fully adjustable heads, the EML5 Series complements any design application.

Category: Tag:

Specifications

  • Injection molded thermoplastic ABS housing
  • UL-94v-0 Flame rating - Flame Retardant
  • Operating temperature: 32˚F - 104˚F (0˚C - 40˚C)
  • Input power 1.15W at 120/277VAC
  • Remote output power 2.4W at 3.6VDC
  • Supports up to two (2) single or one (1) double 3.6VDC NICOR remote lamps
  • 90 minute capacity (including remote lamps)



Part Numbers:

EML5-10-UNV-WH - White
EML5-10-UNV-WH-R - White with Remote

Downloads

– EM Catalog
– Sell Sheet
– Spec Sheet
– Installation Instructions
