LED EMERGENCY OUTDOOR TEAR DROP

The LED Emergency Outdoor Tear Drop combines 90-minute emergency lighting with a low-profile, architectural design. The EOT is designed for outdoor use, with an optional cold-weather kit for added reliability in northern climates. The EOT comes standard with a photocell and wall switch, allowing users added energy efficiency and the ability to control the light from a switch. A non-emergency unit is available for locations not requiring battery-backup, providing a uniform look for all fixtures.



Specifications

  • Input voltage of 120/277VAC
  • Maintenance-free NiCad battery provides 90-minute emergency operation
  • LED indicator light & test button with self-diagnostics standard
  • Photocell standard with wall switch control
  • Operating Temperature:
    • EM: 32°F to 122°F (0°C to +50°C)
    • Non-EM and EM Cold Weather: -13°F to +122°F (-25°C to +50°C)
EOT
2700K
Warm
5000K
Cool

1074
Lumens

1158
Lumens

13.4
Input Watts

13.4
Input Watts

80.1
lm/W

86.4
lm/W

83
CRI

83
CRI

IES Download

IES Download

Part Numbers:

 2700K:EOT1MV2K
 5000K:EOT1MV5K
EOT
2700K
Warm
5000K
Cool

1074
Lumens

1158
Lumens

13.4
Input Watts

13.4
Input Watts

80.1
lm/W

86.4
lm/W

83
CRI

83
CRI

IES Download

IES Download

Part Numbers:

 2700K:EOT1MV2K
 5000K:EOT1MV5K
