LED EMERGENCY OUTDOOR TEAR DROP

The LED Emergency Outdoor Tear Drop combines 90-minute emergency lighting with a low-profile, architectural design. The EOT now features CCT selectability, allowing the user to chose their desired color temperature. The EOT is designed for outdoor use, with an optional cold-weather kit for added reliability in colder climates. The EOT comes standard with a photocell providing users added energy efficiency. An internal selector switch allows bypassing the photocell to control the unit from a wall switch. A non-emergency unit is available for locations not requiring battery-backup, providing a uniform look for all fixtures.



Categories: Tag:

Specifications

  • Polycarbonate lens
  • Dual emitter array that enables CCT selection of 3500K/4000K/5000K
  • >80 CRI to improve safety and color definition in public places
  • Input voltage of 120-277VAC, 50/60Hz
  • Power Factor = ≥0.9
  • THD = ≤20%
  • AC only model operating temp rating : -40°F to 113°F (-40°C to 45°C)
  • Emergency model operating temp rating : 32°F to 113°F (0°C to 45°C)
  • Emergency Cold Weather model operating temp rating : -4°F to 113°F (-20°C to 45°C)
  • 2.5kV surge protection standard

Downloads

– Sell Sheet

– Spec Sheet
– Installation Instructions

– ies Files

EOTv2
3500K
Warm Neutral		4000K
Neutral		5000K
Cool

1740
Lumens

1815
Lumens

1776
Lumens

13.3
Input Watts

13.3
Input Watts

13.3
Input Watts

131
lm/W

137
lm/W

134
lm/W

81
CRI

81
CRI

81
CRI

Part Number:

 Select:EOT2UNVSBZP8
EOTv2
3500K
Warm Neutral		4000K
Neutral		5000K
Cool

1740
Lumens

1815
Lumens

1776
Lumens

13.3
Input Watts

13.3
Input Watts

13.3
Input Watts

131
lm/W

137
lm/W

134
lm/W

81
CRI

81
CRI

81
CRI

Part Number:

 Select:EOT2UNVSBZP8
