LED RECESSED DOWNLIGHTS

The DLR2 and DLR3 combines price, performance and design all in one package. Compatible with most common recessed housings, this luminaire delivers incredible color accuracy with 90+ CRI and flexible dimming capabilities. The DLR2 and DLR3 are an ideal commercial, retail, institutional, or residential downlight choice for retrofit or new construction.

^

* DLR2     ^ DLR3

Specifications

  • Available in round or round baffle
  • Greater than 90 CRI; R9 greater than 50
  • Reported lifetime >36,000 Hours
  • 120V Input Voltage
  • Dimmable to less than 10% with most standard TRIAC dimmers
  • Operating Temperature: 0° to 104°F (-18°C to 40°C)
DLR2
2700K
Warm
3000K
Warm White
4000K
Neutral

600
Lumens

642
Lumens

657
Lumens

8.7
Input Watts

8.7
Input Watts

8.7
Input Watts

69.0
lm/W

73.8
lm/W

75.5
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DLR2-10-120-2K
 3000K:DLR2-10-120-3K
 4000K:DLR2-10-120-4K
DLR3
2700K
Warm
3000K
Warm White
4000K
Neutral

558
Lumens

614
Lumens

675
Lumens

8.0
Input Watts

8.0
Input Watts

8.0
Input Watts

69.8
lm/W

76.7
lm/W

84.4
lm/W

91
CRI

91
CRI

91
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DLR3-10-120-2K
 3000K:DLR3-10-120-3K
 4000K:DLR3-10-120-4K
DLR2
2700K
Warm
3000K
Warm White
4000K
Neutral

600
Lumens

642
Lumens

657
Lumens

8.7
Input Watts

8.7
Input Watts

8.7
Input Watts

69.0
lm/W

73.8
lm/W

75.5
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DLR2-10-120-2K
 3000K:DLR2-10-120-3K
 4000K:DLR2-10-120-4K

DLR3
2700K
Warm
3000K
Warm White
4000K
Neutral

558
Lumens

614
Lumens

675
Lumens

8.0
Input Watts

8.0
Input Watts

8.0
Input Watts

69.8
lm/W

76.7
lm/W

84.4
lm/W

91
CRI

91
CRI

91
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DLR3-10-120-2K
 3000K:DLR3-10-120-3K
 4000K:DLR3-10-120-4K
