NICOR EMERGENCY 20W INVERTER PACK

The EMI200 is a 20 watt LED emergency inverter-style driver for field installation that enables normal and emergency operation of a switched or non-switched LED fixture. The EMI200 allows for emergency operation of most line-voltage LED fixtures without the need to access wiring within the low-voltage side of the fixture. During a power failure, the EMI200 activates emergency mode to maintain output at 20 watts to the fixture without light degradation for a 90 minute duration. The EMI200 contains a battery, charger, and inverter circuit in a single housing.



Specifications

  • Constant power design provides 100% lumen output on fixtures up to 20 watts for >90 minutes
  • 120/277VAC 50/60Hz input voltage
  • Long life high temperature Ni-Cad battery
  • Single piece test switch/charge indicator included
  • 24 hour recharge time



Part Number:

EMI200-1-UNV
