LED LINEAR STRIP

The LS1 LED Linear Strip brings a slim design to task and general ambient lighting for surface mount ceiling applications. This economical, energy-efficient lighting solution is a perfect alternative to 2-lamp fluorescent strips and some wraparound fixtures. The LS1’s milky white lens provides a more polished, higher-end look to the fixture and yet is an affordable alternative for retail, light industrial, warehouse and residential utility applications.



Specifications

  • Universal input 120 ‐277VAC
  • Driver delivers full-range dimming from 0 - 10VDC
  • Advanced optical design generates even light distribution, eliminates hotspots, and provides glare-free illumination
  • Full length acrylic diffuser for even light distribution
  • Operating temperature of 0° to 120°F (-18°C to 49°C)
  • Meets FCC Part 15, Subpart B, Class A standards for conducted and radiated emissions
  • Easy surface mount installation
LS1-10S


3000K
Warm White
4000K
Neutral
5000K
Cool

3001
Lumens

2836
Lumens

3074
Lumens

25.6
Input Watts

25.6
Input Watts

25.6
Input Watts

117.5
lm/W

111.0
lm/W

120.3
lm/W

86
CRI

86
CRI

86
CRI

IES Download

IES Download

IES Download

Part Numbers:

 3000K:LS1-10S-UNV-30
 4000K:LS1-10S-UNV-40
 5000K:LS1-10S-UNV-50
LS1-10H


3000K
Warm White
4000K
Neutral
5000K
Cool

5557
Lumens

5251
Lumens

5692
Lumens

46.7
Input Watts

46.7
Input Watts

46.7
Input Watts

119.0
lm/W

112.5
lm/W

122.0
lm/W

86
CRI

86
CRI

86
CRI

IES Download

IES Download

IES Download

Part Numbers:

 3000K:LS1-10H-UNV-30
 4000K:LS1-10H-UNV-40
 5000K:LS1-10H-UNV-50
LS1-8-10S

4000K
Neutral
5000K
Cool

8247
Lumens

8338
Lumens

70
Input Watts

70
Input Watts

117.8
lm/W

119.1
lm/W

85
CRI

85
CRI

IES Download

IES Download

Part Numbers:

 4000K:LS1-8-10S-UNV-40
 5000K:LS1-8-10S-UNV-50
LS1-10S
3000K
Warm White
4000K
Neutral
5000K
Cool

3001
Lumens

2836
Lumens

3074
Lumens

25.6
Input Watts

25.6
Input Watts

25.6
Input Watts

117.5
lm/W

111.0
lm/W

120.3
lm/W

86
CRI

86
CRI

86
CRI

IES Download

IES Download

IES Download

Part Numbers:

 3000K:LS1-10S-UNV-30
 4000K:LS1-10S-UNV-40
 5000K:LS1-10S-UNV-50

LS1-10H
3000K
Warm White
4000K
Neutral
5000K
Cool

5557
Lumens

5251
Lumens

5692
Lumens

46.7
Input Watts

46.7
Input Watts

46.7
Input Watts

119.0
lm/W

112.5
lm/W

122.0
lm/W

86
CRI

86
CRI

86
CRI

IES Download

IES Download

IES Download

Part Numbers:

 3000K:LS1-10H-UNV-30
 4000K:LS1-10H-UNV-40
 5000K:LS1-10H-UNV-50

LS1-8-10S
4000K
Neutral
5000K
Cool

8247
Lumens

8338
Lumens

70.0
Input Watts

70.0
Input Watts

117.8
lm/W

119.1
lm/W

85
CRI

85
CRI

IES Download

IES Download

Part Numbers:

 3000K:LS1-8-10S-UNV-30
 4000K:LS1-8-10S-UNV-40
 5000K:LS1-8-10S-UNV-50
