PrimeChime Plus 2 – Mini Video Compatible Doorbell Chime Kit with Ring Adapter
The PrimeChime Plus 2 Mini® keeps all the popular features of NICOR’s PrimeChime Plus 2® electronic doorbell while shrinking the unit to fit into a single gang junction box. Compatible with many video doorbell systems, the PRMC combines both line voltage and low voltage into a single unit and offers…
The PrimeChime Plus 2 Mini® keeps all the popular features of NICOR’s PrimeChime Plus 2® electronic doorbell while shrinking the unit to fit into a single gang junction box. Compatible with many video doorbell systems, the PRMC combines both line voltage and low voltage into a single unit and offers a paintable, screwless faceplate for simple installation and a seamless look. Separate melodies for front and rear doors allows you to keep track of exactly which door to answer. NICOR’s lighted button makes your doorbell easily visible to visitors at all times of day, welcoming them to your home. The PRMC is also compatible with many video doorbell systems, increasing the security of your home with a reliable, minimal door chime kit.
- Compatible with many popular video doorbell cameras (voice-guided setup)
- Selectable chime tones (5) and volume levels (5) for customizable alerts
- Compact design fits standard single-gang wall boxes
- Integrated transformer combines line and low voltage in a single unit
- Optional doorbell buttons available in stucco and decorative designs
Color Options:
Ordering information
Downloads
Specifications
Listings & certifications
- UL Certified
- FCC Class B
- Patent Pending
Features
Construction
- ABS Housing
- Combines line voltage and low voltage in a single unit
- Screwless ABS Faceplate
- Two-wire pigtail for line voltage input
- Multiple poke-in connectors for low voltage output for front and back doorbells
- Matte white faceplate is field paintable
Electrical
- Integrated transformer
- Input: 120VAC/60Hz
- Output: 24VAC max
- Digital control board with speaker
- Five selectable melodies : Ding Dong, Westminster, 3 note, 5 note, and 7 note
- Five selectable volume levels
- Voice guided setup during selection
Installations
- Installs quickly into most non-metallic single-gang junction boxes
- Includes two lighted rectangle doorbell buttons
- Compatible with many popular video doorbell buttons (see compatibility list and/or test for compatibility before installation)
- Able to drive up to 2 video doorbells at the same time.
- Daisy chain up to 10 PrimeChime Plus Mini® units (max 400Ft total wire length. Each requires 120VAC input)
- Doorbell buttons connect with 18ga-22ga solid wire (max 100Ft distance)
- For installations where higher power surge may be possible, NICOR recommends installing additional surge protection at the electrical distribution panels
Full Listings
- UL Certified
- FCC Class B
- Patent Pending
Warranty
- 1 year limited system warranty standard
- Warranty does not cover product failure due to an overvoltage event (power surge)
