SQUARE RECESSED LED DOWNLIGHT

The DQRs are everything you love about NICOR’s recessed downlighting family with the added design aesthetic of a square trim. Compatible with most recessed housings, this luminaire delivers incredible color accuracy with 90+ CRI and flexible dimming capabilities. The DQRs are an ideal commercial, retail, institutional or residential downlight choice for retrofit (except the DQR2) or new construction.

*

* DQR2   ^ DQR3, DQR5, DQR6

Specifications

  • Available in square (DQR2 only) and square baffle
  • Greater than 90 CRI; R9 greater than 50
  • Reported lifetime:
    • >36,000 Hours (DQR2)
    • >50,000 Hours (all others)
  • 120V Input Voltage
  • Dimmable to less than 10% with most standard TRIAC dimmers
  • Operating Temperature: 0° to 120°F (-18°C to 49°C)
  • NICOR’s recessed housings required for DQR2
DQR2

2700K

3000K

4000K

Warm

Warm White

Neutral

581
Lumens

628
Lumens

687
Lumens

8.9
Input Watts

8.9
Input Watts

8.9
Input Watts

65.3
lm/W

70.6
lm/W

77.2
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR2-10-120-2K
 3000K:DQR2-10-120-3K
 4000K:DQR2-10-120-4K

DQR3

2700K

3000K

4000K

Warm

Warm White

Neutral

531
Lumens

552
Lumens

573
Lumens

8.9
Input Watts

8.9
Input Watts

8.9
Input Watts

59.5
lm/W

61.9
lm/W

64.2
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR3-10-120-2K
 3000K:DQR3-10-120-3K
 4000K:DQR3-10-120-4K

DQR5

2700K

3000K

4000K

Warm

Warm White

Neutral

999
Lumens

1039
Lumens

1079
Lumens

15.9
Input Watts

15.9
Input Watts

15.9
Input Watts

62.9
lm/W

65.5
lm/W

68.0
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR5-10-120-2K
 3000K:DQR5-10-120-3K
 4000K:DQR5-10-120-4K

DQR6

2700K

3000K

4000K

Warm

Warm White

Neutral

1010
Lumens

1050
Lumens

1091
Lumens

15.6
Input Watts

15.6
Input Watts

15.6
Input Watts

65.0
lm/W

67.5
lm/W

70.1
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR6-10-120-2K
 3000K:DQR6-10-120-3K
 4000K:DQR6-10-120-4K

DQR2
2700K
Warm
3000K
Warm White
4000K
Neutral

581
Lumens

628
Lumens

687
Lumens

8.9
Input Watts

8.9
Input Watts

8.9
Input Watts

65.3
lm/W

70.6
lm/W

77.2
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR2-10-120-2K
 3000K:DQR2-10-120-3K
 4000K:DQR2-10-120-4K

DQR3
2700K
Warm
3000K
Warm White
4000K
Neutral

531
Lumens

552
Lumens

573
Lumens

8.9
Input Watts

8.9
Input Watts

8.9
Input Watts

59.5
lm/W

61.9
lm/W

64.2
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR3-10-120-2K
 3000K:DQR3-10-120-3K
 4000K:DQR3-10-120-4K

DQR5
2700K
Warm
3000K
Warm White
4000K
Neutral

999
Lumens

1039
Lumens

1079
Lumens

15.9
Input Watts

15.9
Input Watts

15.9
Input Watts

62.9
lm/W

65.5
lm/W

68.0
lm/W

92
CRI

92
CRI

92
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR5-10-120-2K
 3000K:DQR5-10-120-3K
 4000K:DQR5-10-120-4K

DQR6
2700K
Warm
3000K
Warm White
4000K
Neutral

1010
Lumens

1050
Lumens

1091
Lumens

15.6
Input Watts

15.6
Input Watts

15.6
Input Watts

65.0
lm/W

67.5
lm/W

70.1
lm/W

91
CRI

91
CRI

91
CRI

IES Download

IES Download

IES Download

Part Numbers:

 2700K:DQR6-10-120-2K
 3000K:DQR6-10-120-3K
 4000K:DQR6-10-120-4K
