IMS3DRLY Series
IMS Enabled DALI-2 Relay Module
Product description
The IMS3DRLY DALI-2 Relay Module is a compact relay module for direct control of 277VAC loads via DALI.
- Compact DALI-2 relay module provides direct switching control of 277VAC lighting loads
- Powered directly from the DALI bus with support for IEC 62386-102 and IEC 62386-208 standards
- One normally open relay contact rated up to 5A continuous current with 60A inrush capability
- Zero-cross switching technology helps reduce electrical stress and improve relay longevity
- Compatible with NICOR IMS DALI control systems and installs in standard junction boxes
Color Options:
Downloads
Specifications
Listings & certifications
Listings & Certifications
- DALI Alliance Certified
- IP20 Ingress Protection
Other Certifications
- DALI-2 control unit according to IEC 62386-102
- Supports DALI-2 specification IEC 62386-208
- Meets IEC CISPR 15 Standards
- Meets EMC Standard EN 61547
- Meets EMC Standard EN 50015
- Meets EMC Standard EN 61347-2-11
- Meets EMC Standard EN 61347-1
Features
Construction
- Halogen-free, non-flammable polycarbonate housing
- 6 push-to-release wire ports: 4 DALI-2 output, 2 relay ports
- Operates in temperatures from -4°F to 140°F (-20°C to 60°C)
- Storage temperature: -4°F to 167°F (-20°C to 75°C)
Electrical
- Powered via DALI-2 bus (DALI-voltage according to IEC 62386 (2014))
- Relay output switch on/off voltage : 277VAC
- Max breaking current: 12A
- Max inrush current: 60A
- Max continuous current: 5A
- One normally open relay contact
- DALI-2 control unit according to IEC 62386-102
Installations
- Wire ports accept 20-16AWG solid or stranded wire
- Install into standard junction box behind sensor or switch
Full Listings
- DALI-2
- CE
- UKCA
- DALI IEC 62386-102
- DALI IEC 62386-208
- EN 61547
- EN 50015
- IEC CISPR 15
- EN 61347-2-11
- EN 61347-1
Warranty
- 5-year limited system warranty
- Warranty does not cover product failure due to an overvoltage event (power surge)
