SURFACE & PENDANT DECORATIVE LED CEILING MOUNT

Combining a classic white lens with a stylish round nickel frame, you can add style and charm to your home or office. This LED surface mount decorative family provides general illumination, high performance, and exceptional brightness control in residential and light commercial applications, and is ideal for use in foyers, hallways, bedrooms, offices, utility work areas, stairways, and many other rooms in the house. Available in 14”, 16”, and 18” diameters.

Specifications

  • Universal input 120 ‐277VAC
  • Operating temperature of 0° to 104°F (-18°C to 40°C)
  • Die-formed cold rolled steel frame
  • Mounts flush to ceiling with optional pendant mounting
  • Finish in Nickel

Downloads

Spec Sheet
Installation Instructions



30014


3000K
Warm White
4100K
Neutral

1850
Lumens

1940
Lumens

24
Input Watts

24
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30014-LED-NK-30K
 4100K:30014-LED-NK-41K
30014-PLED-NK-41K  Pendant Mount
30016


3000K
Warm White
4100K
Neutral

2160
Lumens

2260
Lumens

28
Input Watts

28
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30016-LED-NK-30K
30016-PLED-NK-30K  Pendant Mount
 4100K:30016-LED-NK-41K
30016-PLED-NK-41K  Pendant Mount
30018


3000K
Warm White
4100K
Neutral

2700
Lumens

2830
Lumens

35
Input Watts

35
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30018-LED-NK-30K
30018-PLED-NK-30K  Pendant Mount
 4100K:30018-LED-NK-41K
30018-PLED-NK-41K  Pendant Mount
30014
3000K
Warm White
4100K
Neutral

1850
Lumens

1940
Lumens

24
Input Watts

24
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30014-LED-NK-30K
 4100K:30014-LED-NK-41K
30014-PLED-NK-41K  Pendant Mount

30016
3000K
Warm White
4100K
Neutral

2160
Lumens

2260
Lumens

28
Input Watts

28
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30016-LED-NK-30K
30016-PLED-NK-30K  Pendant Mount
 4100K:30016-LED-NK-41K
30016-PLED-NK-41K  Pendant Mount

30018
3000K
Warm White
4100K
Neutral

2700
Lumens

2830
Lumens

35
Input Watts

35
Input Watts

78
lm/W

78
lm/W

80
CRI

80
CRI



IES Download

Part Numbers:

 3000K:30018-LED-NK-30K
30018-PLED-NK-30K  Pendant Mount
 4100K:30018-LED-NK-41K
30018-PLED-NK-41K  Pendant Mount
