NICOR IMS Controls
An Enterprise Level DALI Lighting Control System
NICOR’s Illumination Management System (IMS) introduces simple installation with an easy-to-use user interface. The Digital Addressable Lighting Interface (DALI) enabled system provides individual fixture control to multi-site empowerment with our Master Control Unit (MCU). Developed with energy management in mind, this system is perfect for industrial facilities, data centers, and large commercial buildings.
Downloads
The IMS3PIRDT occupancy sensor integrates a passive infrared presence detector and a digital microphone. This sensor also provides light intensity (daylight) measurement giving it the ability to work in daylight harvesting applications. The sensor provides a presence detection zone with a diameter of 35.4 feet at a mounting height of 9.8 feet, making it ideal for covering a typical office room or an area in an open office space. At mounting heights ranging from 16.4 to 39.3 feet, the detection area extends to 839.6 square feet. The occupancy sensor mounts with spring snaps in false ceilings.
The IMS3PIR is a compact, high performance, DALI-2 sensor that mount on ceilings. This sensor provides presence detection and lighting control. The sensor is equipped with movement detection (PIR) and light intensity (daylight) measurement capability giving it the ability to work in daylight harvesting applications.
The IMS3DXC DALI-2 Input Controller provides DALI-2 control of Low Voltage devices such as switches or sensors. Powered via the DALI-2 bus, it is compatible with the NICOR IMS 3.0.
The IMS3D0-10VRLY is a DALI-2 to 0/1-10V converter, enabling 0/1-10V loads to be controlled via DALI communication systems. Controlling one standard contactor or 2,770 VA of fixtures, the IMS3D0-10VRLY allows fixtures without a DALI input to be integrated into a DALI circuit. Powered via the DALI bus, it is compatible with the NICOR IMS 3.0. The device supports the DALI specification IEC 62386‑208 (Device Type 7, “switching function”) for non-dimmable loads and the DALI specifications IEC 62386‑206 (Device Type 5, “converter”) for loads dimmable via the 1 – 10 V interface, respectively (max. 50mA current sink).
The NICOR IMS 3.0 is a DALI-2 (Digital Addressable Lighting Interface) lighting management system that can provide controls to a complete lighting system. Manual controls, dimming, scheduling, daylight harvesting and motion sensing are all available as additional features on the system. The IMS allows for simple, cost-effective lighting installations with full luminaire control through DALI-2 control protocols.
The IMS3SWDS is a touch sensitive, glass front DALI-2 wall panel control device. Compatible with the NICOR IMS 3.0, it controls IMS enabled fixtures with on-off and dimming. This switch can control a single DALI-2 group.
The IMS1SWMD is a Decora Style SPDT momentary rocker switch [(ON)-OFF-(ON)] that is compatible with the NICOR IMS 2.0 to control fixture on-off and dimming functions.
