2” LED NEW CONSTRUCTION HOUSING

The 12300A-LED is designed with a high efficiency LED driver and has IDEAL connections that allow for quick, snap-in connection of NICOR® 2” D-series LED downlights. Suitable for new construction in residential and commercial applications. Suitable for direct contact with insulation. 120-277V housing.



Specifications

  • Easy installation for new construction projects
  • Allows for quick, snap-in connection of 2” D-Series downlights
  • Rated for use in damp locations
  • Airtight housing limits the exchange of air between ceiling plenum and heated/cooled areas
  • Washington State Energy Code approved to meet restricted airflow requirements
  • 4½” height allows use in 2” x 6” joist construction
  • Listed for through-branch circuit wiring and includes several ¾” knockouts
  • Heavy-gauge NICOR captive hanger bars provide greater stability, allowing housing to be positioned at any point within a 24” joist span, then locked in place with set screws
  • Unique hanger bar lip design helps align can to joist
  • Four double-headed captive nails provide for ease of installation
  • Bars can be repositioned 90° on plaster frame without tools
  • Score lines allow bars to be shortened without tools to accommodate a 12” joist span
  • Input Voltage 120-277V AC
  • Full-range dimming from 0-10VDC
  • ONLY COMPATIBLE WITH NICOR 2” SERIES



Part Number:

12300A-LED
